Forney 314 AC/DC Welder, 230V/180A 57Lb

Forney 314 AC/DC Welder, 230V/180A 57Lb

The Forney 314 AC/DC Welder is a versatile, heavy-duty stick welder built for serious fabrication, repair, and maintenance work. With AC/DC capability and up to 235 amps of output, it handles everything from thin sheet metal to 1/2" steel with confidence. Designed to be ready to weld right out of the box, it combines solid performance, durable construction, and straightforward controls—because when it’s time to weld, you don’t want to spend half the day setting up.

Country of Origin
Varies by production batch

Key Features / Specifications

• Model / Part Number: 314
• Brand: Forney
• Product Type: AC/DC stick (arc) welder
• Input Voltage: 230V
• Phase: Single phase
• Frequency: 60 Hz
• Output Range: 45–235 amps
• Rated Output: Up to 235A
• Welding Capacity: 24 gauge up to 1/2" material thickness
• Duty Cycle:
  • 50% @ 150A (AC)
  • 20% @ 230A (AC)
  • 20% @ 180A (DC)
  • 35% @ 135A (DC)
• Cable Lengths:
  • 15 ft electrode holder cable
  • 15 ft ground cable with clamp
  • 15 ft power cord
• Connections: Dinse-style connectors for easy polarity changes and service
• Cooling System: Fan-cooled for extended operation
• Controls: Illuminated ON/OFF switch
• Construction: Durable steel housing with large work envelope
• Dimensions: 12" x 16-1/2" x 30-1/2"
• Weight: Approx. 108–116 lbs (depending on configuration)

Included

• (1) 15 ft electrode holder cable
• (1) 15 ft ground cable with clamp
• (1) 15 ft power cord
• Electrode holder (stinger)

Ideal For

• Farm, ranch, and shop welding applications
• Repair work on equipment, trailers, and structural steel
• Users needing AC/DC flexibility for different rod types and materials
• Projects ranging from light sheet metal to heavy steel fabrication
• Anyone who wants a welder that’s ready to go out of the box—just add rod and a good excuse to strike an arc
