Hydraulic Fitting, 5/8"X5/8" Female Jic 90 Deg

The 10G-10FJX90S Hydraulic Fitting is a 90° female JIC hydraulic coupling designed to provide a dependable, leak-resistant connection in tight routing applications. Built with the MegaCrimp® system’s patented “C” insert, it helps form a concentric seal by evenly distributing crimping forces while accommodating different hose constructions and wall thicknesses—reducing inventory needs by allowing one size to fit multiple hose ODs on one- and two-wire hoses.

Country of Origin
Varies by production batch

Key Features / Specifications

• Model / Part Number: 10G-10FJX90S
• Brand / Series: MegaCrimp®
• Product Type: Hydraulic fitting — Female JIC 90°
• Fitting Nominal Size: 5/8 in.
• Hose ID: 5/8 in.
• Thread Size: 7/8"-14
• Thread Pitch: 14
• Nut Hex Size: 1 in.
• Overall Length: 3.37 in.
• Drop Length: 1.42 in.
• Cutoff Length: 1.93 in.
• Seal / Design Feature: Patented “C” insert for even crimp-force distribution and concentric sealing
• Compatibility Benefit: One size accommodates multiple hose ODs on one- and two-wire hoses

Ideal For

• Hydraulic hose assemblies needing a 90° female JIC connection for cleaner routing
• Crimped hose builds where leak control and consistent sealing are critical
• Shops simplifying stocking across varying hose constructions/wall thicknesses
• Equipment maintenance and repairs requiring reliable hydraulic connections
