Hydraulic Hose Fitting, 3/8" Female Flareless

Hydraulic Hose Fitting, 3/8" Female Flareless

The 6G-6FFA Hydraulic Hose Fitting is a MegaCrimp® flareless tube (MFA) straight coupling built for durable, leak-resistant hydraulic hose assemblies. It features a robust “bite-the-wire” crimp design and a patented pre-assembled “C” insert that helps accommodate different hose constructions and wall thicknesses while distributing crimp forces evenly to form a concentric seal. Finished with TuffCoat™ plating for significantly improved corrosion resistance, it’s engineered for demanding service and long life (tested to 1 million impulse cycles).

Country of Origin
Varies by production batch

Key Features / Specifications

• Model / Part Number: 6G-6FFA
• Product Type: Hydraulic MegaCrimp® hose fitting
• Configuration: Straight
• End Type: MFA
• Fitting Type: Flareless tube
• Dash Size: 6
• Hose Dash Size: 6
• Hose Inside Diameter: 0.3740 in (3/8")
• Thread Size: 9/16-18
• Mating Angle: 24°
• Seal Type: Compression
• Swivel: No
• Material: Steel
• Coating / Finish: TuffCoat™
• Performance: Bite-the-wire crimp; tested to 1 million impulse cycles
• Hose Compatibility: Designed for various hose ODs on 1-wire and 2-wire braid hydraulic hose
• UPC: 072053173321
• Corrosion Resistance Claim: 347% better than SAE standard (TuffCoat™); some styles available with TuffCoat™ Xtreme™ up to 583% better than SAE standard

Ideal For

• Building hydraulic hoses needing a 3/8" (Dash 6) flareless tube connection
• Applications requiring a straight, non-swivel compression-seal fitting
• Equipment exposed to moisture where enhanced corrosion resistance is important
• Shops wanting a coupling system that helps simplify inventory across multiple hose constructions
