Metric Female DIN Heavy Series Hydraulic Fitting

The 8G-14FDHORX90 Metric Female DIN Heavy Series Hydraulic Fitting is a 90° MegaCrimp® coupling designed for heavy-series DIN applications where a tight routing angle and a reliable seal matter. Built around the patented MegaCrimp® design, the internal “C” insert helps accommodate different hose constructions and wall thicknesses while distributing crimp forces evenly to form a concentric, leak-resistant seal—which is great, because hydraulic leaks are never just “a little leak.”

Country of Origin
Varies by production batch

Key Features / Specifications

• Model / Part Number: 8G-14FDHORX90
• Brand / Series: MegaCrimp® coupling
• Product Type: Hydraulic hose fitting / 90° crimp coupling
• Connection Type: Metric Female DIN Heavy Series (90°)
• Thread Size 1: M22 × 1.5
• Thread Pitch: 1.5
• Tube OD: 14 mm (Tube OD 1: 14 mm)
• Hose ID 1: 1/2 in
• Nut Hex Size: 27 mm
• Cutoff Length: 1.64 in
• Drop Length: 2.01 in
• Overall Length: 3.11 in
• Seal Design: Patented MegaCrimp® “C” insert for even crimp-force distribution and concentric sealing
• Compatibility Benefit: One size supports multiple hose ODs across varying constructions and wall thicknesses
• Hose Types: Compatible with one- and two-wire hoses

Ideal For

• Building DIN heavy series hose assemblies with a 90° turn for cleaner routing
• Hydraulic systems needing a leak-resistant crimp seal in demanding service
• Equipment repairs where metric M22×1.5 threads and 14 mm tube OD are required
• Shops looking to simplify inventory with a coupling that fits multiple hose constructions
• Anyone who prefers their hydraulics to stay pressurized—not personalized
