Metric Female DIN Light Series Hydraulic Fitting

The 8G-15FDLORX90 Metric Female DIN Light Series Hydraulic Fitting is a 90° female DIN Light (L-series) hose fitting designed for dependable hydraulic connections in tight routing areas. Built for use with MegaCrimp® couplings, it utilizes the patented “C” insert design to help create a leak-proof, concentric seal while accommodating a range of hose constructions and wall thicknesses—helping simplify inventory by allowing one size to fit multiple hose ODs.

Country of Origin
Varies by production batch

Key Features / Specifications

• Model / Part Number: 8G-15FDLORX90
• Product Type: Metric female DIN Light (L-series) hydraulic fitting
• Style: 90° elbow
• Thread Size: M22 x 1.5
• Thread Pitch: 1.5
• Tube OD: 15 mm
• Nut Hex Size: 27 mm
• Hose ID: 1/2 in
• Cutoff Length: 1.59 in
• Drop Length: 1.65 in
• Overall Length: 3.06 in
• Coupling System: MegaCrimp® (patented “C” insert for even crimp force distribution and concentric seal)

Ideal For

• Hydraulic hose assemblies needing a Metric Female DIN Light (L-series) connection
• Tight installations requiring a 90° fitting for cleaner hose routing
• Standardizing hose builds with MegaCrimp® components across varying hose constructions
• Applications where a leak-resistant crimped connection is critical
