Metric Female DIN Light Series Hydraulic Fitting

The 6G-10FDLORX90 Metric Female DIN Light Series Hydraulic Fitting is a 90° female DIN Light (L-series) fitting designed for reliable hydraulic connections using a 10 mm tube OD and M16 x 1.5 metric threads. Engineered for use with MegaCrimp® coupling systems, it supports consistent, leak-resistant assemblies and helps streamline inventory by accommodating multiple hose constructions and wall thicknesses.

Country of Origin
Varies by production batch

Key Features / Specifications

• Model / Part Number: 6G-10FDLORX90
• Product Type: Metric female DIN Light Series hydraulic fitting (90°)
• Series: DIN Light (L-Series)
• Connection / Style: Female DIN Light, 90°
• Thread Size: M16 x 1.5
• Thread Pitch: 1.5
• Tube OD: 10 mm
• Nut Hex Size: 19 mm
• Hose ID: 3/8 in
• Overall Length: 2.37 in
• Cutoff Length: 1.27 in
• Drop Length: 1.44 in
• MegaCrimp® Compatibility: Uses MegaCrimp® design intended to support a leak-proof concentric seal across varying hose constructions and wall thicknesses

Ideal For

• Hydraulic lines requiring a 90° DIN Light (L-series) female connection
• Systems using 10 mm tube OD with M16 x 1.5 threads
• Hose assemblies built around MegaCrimp® coupling platforms
• Equipment repairs where compact right-angle routing is needed
• Reducing leaks and improving reliability in mobile and industrial hydraulics
