Needle Bearing, 1.000"X1.312"X1.000"

Needle Bearing, 1.000"X1.312"X1.000"

The BH1616 Needle Bearing is a heavy series full-complement needle roller bearing designed to deliver maximum load capacity in a compact envelope. With no inner or outer rings, this bearing uses the mating shaft and housing as raceways, allowing for a low cross-section design that handles high radial loads efficiently. Built as part of the BH Heavy Series, it features mechanically retained needle rollers for strength and durability—small in size, but definitely not small in capability.

Country of Origin
Varies by production batch

Key Features / Specifications

• Part Number: BH1616
• Product Type: Needle Roller Bearing (Cage Assembly)
• Series: BH – Heavy Series
• Construction: Full complement of mechanically-retained needle rollers
• Closure Type: Unsealed
• Inside Diameter (Shaft): 1.000"
• Outside Diameter (Housing): 1.312"
• Width: 1.000"
• Design: No inner or outer ring
• Raceways: Mating shaft and housing serve as inner and outer raceways
• Load Capability: High radial load capacity in low cross-section design
• Lubrication Option: “-OH” suffix designates oil hole version

Ideal For

• Applications requiring maximum load capacity in limited space
• Equipment where the shaft and housing serve as raceways
• Industrial and agricultural machinery
• Compact mechanical assemblies needing high radial load support
• Installations where a heavy series needle bearing is preferred
