Packard Surge Protector, 120/240V, 72,000A

Packard Surge Protector, 120/240V, 72,000A

The PSP72KA Packard Surge Protector (120/240V, 72,000A) is a heavy-duty surge protection device built to help protect HVAC and other critical equipment from damaging electrical transients. Designed for split-phase 120/240VAC systems, it features a weatherproof enclosure and a parallel connection for straightforward installation. A diagnostic LED provides clear indication of power, ground presence, and surge protection status, and the unit automatically resets to handle multiple surge events over time. It’s Made in the U.S.A. and commonly used at A/C disconnects, small electrical panels, and pool/well pump circuits.

Country of Origin
Made in the U.S.A.

Key Features / Specifications

• Model / Part Number: PSP72KA
• Brand: Ditek (Packard)
• Product Type: Surge protector (SPD)
• Voltage / System: 120/240VAC split-phase (Split Φ 2W + G)
• MCOV: 130/260V
• Peak Surge Current: 72,000A per phase / 36,000A per mode
• Short Circuit Current Rating (SCCR): 10,000A
• Enclosure: Weatherproof
• Installation: Parallel connection for easy install
• Status Indication: Diagnostic LED (power, ground, protection)
• Reset Function: Automatically resets after surge events
• Typical Applications: A/C disconnect, small electrical panels, pool/well pumps
• UPC: 840899107783
• Direct Replacements For:
  • Mars: 83904
  • Supco: SMC150, SMC60
  • Intermatic/Grasslin: AG3000

Ideal For

• Protecting HVAC equipment at the A/C disconnect
• Adding surge protection to small panels or dedicated circuits
• Pool and well pump installations needing a rugged, weather-resistant SPD
• Users who want clear LED diagnostics for power/ground/protection status
• Applications needing a high surge capacity (72,000A/phase) with auto-reset capability
