Pto Ratchet Clutch, B&P 4-Series/Walterscheid 2300 Series

Pto Ratchet Clutch, B&P 4-Series/Walterscheid 2300 Series

The PTO Ratchet Clutch for B&P 4-Series / Walterscheid 2300 Series provides dependable overload protection while helping keep you moving when a blockage hits. Instead of a full stop, the ratchet design transmits torque in pulses during an overload event—often accompanied by an audible clicking—helping the implement work through and clear the obstruction. Once the load drops back below the calibrated torque setting, the clutch automatically re-engages, reducing downtime and improving productivity in tough field conditions.

Country of Origin: Varies by production batch

Key Features / Specifications

• Series fitment: B&P 4-Series / Walterscheid 2300 Series
• Overload function: Pulsating torque ratchet action during overload to help clear blockages
• Auto re-engagement: Re-engages when transmitted torque drops below calibrated value
• Connection 1: SPRING-LOK
• Bore 1: 1 3/8"–6 spline (35 mm)
• Bearing diameter: 1.06" (27 mm)
• Bearing span: 2.93" (74 mm)
• Outside diameter: 3.81" (97 mm)
• Overall length: 6.29" (160 mm)
• Power rating @ 540 RPM: 45 HP (34 kW)
• Power rating @ 1000 RPM: 70 HP (52 kW)
• Torque rating: 8000
• Product weight: 8.15 lb (4 kg)
• Shipping dimensions: 7.163" L × 3.82" H × 3.819" W (18 cm × 10 cm × 10 cm)
• Shipping volume: 104.50 in³ (1712 cm³)
• Shipping weight: 8.15 lb (4 kg)

Ideal For

• PTO-driven implements that need overload protection (choppers, mowers, tillage, and similar equipment)
• Operators who want reduced stoppages when plugging or blockages occur
• Applications where automatic re-engagement helps maintain productivity
• Replacing worn or damaged clutches on B&P 4-Series / Walterscheid 2300 Series drivelines
• High-load conditions where pulsing torque can help clear material without frequent dismounts
