Samasz 2-Rotor Trailed Rake
SKU DUO740
$32,500.00
In stock: 1 available
1
Save this product for later
Customer reviews
Reviews only from verified customers
No reviews yet. You can buy this product and be the first to leave a review.
Samasz 2-Rotor Trailed Rake
Product Details
Brand: Samasz
Weight: 4 520.00 lbs
Standard equipment
Oil operating gearbox with replaceable connecting rods (DUO 740) • Hydraulic folding • Front and rear ground following wheel • Tine loss protection • Swath width regulation • 2-windrow formation • Raking height adjustment • Dismountable arms for transport • Windrow curtain • Warning plates with rear road lights • Tandem wheels • PTO shaft • KENNFIX hydraulic connector
- tine-arm shape with its layout at the rotor has a great impact on windrow forming
- precise and clean material pick-up thanks to the shape and profile of the tines
- tandem chassis ensures ideal ground following
- anti-loss tine protection
- 1 or 2 windrow formation for greater harvest economy
- oil operating gearboxes ensure long life
- tine-arm transport latch (DUO 740)
- KENNFIXX hydraulic connector
- patented hydro-mechanical working height adjustment system
- transport on tandem wheels
- delayed foldaway system thanks to installed sequence valves
- over 10 years of experience in rotary rakes manufacturing
- 2-year warranty
- gearboxes of proven supplier
-
DUO 680 DUO 740 Working width [m/ft] 3,40 - 6,80 / 11’2” - 22’4” 3,70 - 7,40 / 12’1’’-24’3’’ Windrow width [m/ft] 0,80 - 1,50 / 2’7” - 4’11” 0,80 - 1,50 / 2’7” - 4’11” Diameter of the rotor with arms [m/ft] 3,00 / 9'10" 3,30 / 10’10’’ Transport width [m/ft] 3,00 / 9’8” 3,30 / 9'8" Transport width without arms [m/ft] 1,80 / 5'11" 2,55 / 8’4’’ Lifting height on headlands [mm/ft] 490 / 1'60" 490 / 1’60’’ Necessary hydraulic couplers 1 x single acting 1 x double acting 1 x single acting 1 x double acting Working capacity [ha/h/ac/h] ~ 5,00 - 6,50 / ~ 12,50 - 16,00 ~ 8,00 / 20,00 Number of arms per rotor [pcs.] 11 11 The number of disassembled arms per transport carousel [pcs.] - 6 Tines [pcs.] 4 4 RPM 540 540 3-point hitch cat. II II Power demand [HP] from 60 from 60 Tires (with inner tubes) [pcs.] 18 x 8,5 - 8 18 x 8,5 - 8 Weight [kg/lbs] 1720 / 3790 2050 / 4520 PTO shaft tractor - rake: wide-angle with overrunning clutch, built-in: 1. wild-angle, 2. with overload clutch tractor - rake: wide-angle with overrunning clutch, built-in: 1. wild-angle, 2. with overload clutch Depositing swaths on the left on the left
