Start Capacitor, 280-336MFD 250V

Vanguard Start Capacitor, 280-336MFD 250V

The Vanguard BC-280M-250 Start Capacitor is a reliable motor start capacitor designed to deliver strong starting torque for compatible electric motors. Rated for 220/250 VAC operation and 50/60 Hz service, it’s built with a round phenolic case, four 1/4" spade terminals, and a wide -40°C to +65°C temperature range for dependable performance in real-world installations—because motors already have enough trouble starting on Mondays.

Country of Origin
Made in Mexico

Key Features / Specifications

• Brand: Vanguard
• Model / Part Number: BC-280M-250
• Alternate / Reference Number: 61B7D250270NCSX
• Product Type: Start capacitor
• Capacitance: 270–324 uF (MFD)
• Voltage Rating: 220/250 VAC
• Frequency: 50/60 Hz
• Temperature Range: -40°C to +65°C (-40°F to 149°F)
• Case Style / Material: Round phenolic
• Diameter: 2-1/16" ± 0.02"
• Length: 4-3/8" +0.02"/-0.03"
• Connection Type: Four 1/4" spade terminals
• Resistor: None
• Certifications: UL Recognized
• Weight: 0.60 lbs
• UPC: N/A

Ideal For

• Replacing a failed start capacitor in compatible single-phase motor applications
• Equipment needing dependable starts across 220/250 VAC systems
• Installations exposed to temperature swings where a wide operating range matters
• Techs who prefer UL Recognized components and standard spade terminal hookups
