Start Capacitor, 829-995MFD 125V

Vanguard Start Capacitor, 829-995MFD 125V

The BC-800 Vanguard Start Capacitor is a high-capacitance motor start capacitor designed to deliver the extra boost needed to get electric motors up and running. Rated at 829–995 MFD (uF) and 110–125 VAC, this round phenolic-cased capacitor is built for reliable performance across a wide temperature range. With four 1/4" spade terminals for easy installation and UL Recognition for safety compliance, it’s a dependable choice when your motor needs a strong start — not a second try.

Country of Origin
Made in Mexico

Key Features / Specifications

• Brand: Vanguard
• Model / Part Number: BC-800
• Alt. Number: 61B7D120829NCSX
• Type: Start Capacitor
• Capacitance: 829–995 MFD (uF)
• Voltage Rating: 110–125 VAC
• Frequency: 50/60 Hz
• Temperature Range: -40°C to +65°C (-40°F to 149°F)
• Case Style: Round Phenolic
• Diameter: 2-1/16 in ± .02 in
• Length: 4-3/8 in +.02 in / -.03 in
• Connection Type: Four 1/4 in Spade Terminals
• Internal Resistor: None
• Certifications: UL Recognized
• Weight: 0.60 lb
• UPC: N/A

Ideal For

• Electric motor start applications
• HVAC, agricultural, and industrial motor systems
• Replacing failed or weak start capacitors
• Equipment operating in wide temperature environments
• Getting motors spinning strong from the first flip of the switch
