SuperCast Electrodes, 3/32"

SUPERCAST

SPECIALLY DESIGNED FOR DIRTY CAST IRON.

THE PROBLEM SOLVER TO USE WHEN ALL OTHERS FAIL

AC/DC REVERSE POLARITY (ELECTRODE +)

GENERAL CHARACTERISTICS:

Unique flux coating on alloyed Bi-metal core wire produces dense, strong, crack-resistant

welds on all types of cast iron. Especially good for contaminated, old, oil-soaked, dirty base

metal. Also recommended for joining cast iron to steel. Use on gray, ductile, Meehanite, and

nodular cast iron. Deposits are machinable.

APPLICATIONS:

Use on sewer pipe, machine bases, transmission or gear housings, sprockets, repair of or

build-up on gears, and any repair of cast iron to steel.

TECHNICAL DATA:

Tensile Strength....................................................... ……………...up to 72,000 psi

Hardness ............................................................................................... Brinell 210

Current .......................................................................... AC or DC reverse polarity

Amperage 40-70 70-120 90-130 110-170

(in) 3/32” 1/8” 5/32” 3/16”

(mm) 2.5 3.25 4.0 5.0

PROCEDURE:

On heavy sections, remove worn, cracked metal, and bevel joint using Chamfertrode or a grinding wheel. When repairing cracks, drill “stop” hole at either end to prevent spreading while welding. On very heavy sections, preheat to approximately 350°F. Use short stringer beads for root pass and peen lightly after removing slag. Use a short to medium arc and the lowest amperage possible to minimize base metal over-heating. When breaking arc, always back whip into weld crater. Weaving two times rod diameter is acceptable for cover beads on multi-pass work. Weld joints should be allowed to slow cool for maximum strength and machinability.
