The TX2500 Hydraulic Cylinder is a heavy-duty tie-rod style cylinder built for dependable performance in agricultural, industrial, and equipment applications. Rated for 2,500 PSI working pressure and backed by a 30-month warranty, this cylinder features a durable black finish, inline ports, and a strong 1" pin size for secure mounting. With a 4" bore and 16" stroke, it delivers powerful push and pull force for a wide range of hydraulic tasks.
Country of Origin: Varies by production batch
Key Features / Specifications
- Product line: TX
- Model: TX2500
- Cylinder type: Tie-rod cylinder
- Bore: 4"
- Stroke: 16"
- Rod diameter: 1.25"
- Working pressure: 2,500 PSI
- Port type: 1/2" NPT
- Port orientation: Inline
- Pin size: 1"
- Color: Black
- Warranty: 30 Month
Performance Ratings
- Max rating: 1,575 (as listed)
- Push: 19,790
- Pull: 28,345
Pin-to-Pin Length
- Retracted (pin-to-pin): 26.25" (26-1/4")
- Extended (pin-to-pin): 42.25" (42-1/4")
Service / Repair Information
- Repair kit part number: 639579
- Repair kit description: RK 40L-125 HYD REP KIT
Ideal For
- Agricultural implements and farm equipment
- Industrial machinery and material handling
- Lifts, dump functions, and equipment actuation
- Replacing worn cylinders with a reliable 4" x 16" tie-rod unit
