Wolverine Welded Hydraulic Cylinder, 2-1/2"X10" w/1-1/4" Rod, 1" Pins, Clevis

Wolverine Welded Hydraulic Cylinder, 2-1/2"X10"

The Wolverine WWCL3010-S Hydraulic Cylinder is a high-quality, welded, double-acting clevis cylinder engineered for dependable performance in agricultural, construction, and industrial applications. Manufactured by Prince, the Wolverine series features durable construction, North American-sourced seals, and a hard chrome-plated rod for long service life.

Designed for 3000 PSI maximum pressure, this 3" bore × 10" stroke cylinder delivers strong, consistent hydraulic power. Equipped with O-ring top ports and cast steel clevis ends, it is fully tested to ensure quality and reliability.

Country of Origin: Varies by production batch

Key Features / Specifications

• Model number: WWCL3010-S
• Type: Welded, double-acting hydraulic cylinder
• Bore: 3"
• Stroke: 10"
• Maximum pressure: 3000 PSI
• Rod diameter: 1-1/2"
• Ports: SAE 8
• Retracted length: 20-1/4"
• Shipping weight: 31 lbs
• Construction highlights:
  • Thread-in gland cap
  • Hard chrome-plated rod
  • North American seals
  • Cast steel clevis ends
  • Thread-on rod clevis
  • High-luster black paint
  • 100% factory tested

End Mounting Details

Rod End Clevis

• Outside width: 2-5/8"
• Inside width: 1-1/8"
• Throat depth: 2-1/8"
• Pin hole diameter: 1"

Base End Clevis

• Outside width: 2-5/8"
• Inside width: 1-1/8"
• Throat depth: 1-7/8"
• Pin hole diameter: 1"

Ideal For

• Agricultural implements
• Log splitters
• Construction equipment
• Industrial machinery
• Hydraulic systems requiring a 3" × 10" 3000 PSI cylinder
